Roofing Metal Shed Single Reduced Tin Plate Sheet

Roofing Metal Shed Single Reduced Tin Plate Sheet
Roofing Metal Shed Single Reduced Tin Plate Sheet
Roofing Metal Shed Single Reduced Tin Plate Sheet Roofing Metal Shed Single Reduced Tin Plate Sheet Roofing Metal Shed Single Reduced Tin Plate Sheet Roofing Metal Shed Single Reduced Tin Plate Sheet

Large Image :  Roofing Metal Shed Single Reduced Tin Plate Sheet

Product Details:
Place of Origin: CHINA
Brand Name: SYL
Certification: CE ISO
Model Number: tinplate
Payment & Shipping Terms:
Minimum Order Quantity: 1 ton
Price: $400-680/Metric Ton
Packaging Details: Standard seaworthy export packing or as customer demands
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, L/C, D/A, D/P
Supply Ability: 5000 Ton/Tons per Month

Roofing Metal Shed Single Reduced Tin Plate Sheet

Description
Certificate: ISO9001, CE Standard: JIS ASTM ASME GB DIN EN
Packing: According To Customer Needs Width:: 300-1500MM,etc
Hardness: T1-T5 Tolerance: ±1%
Tin Coating: 1.1-5.6 Shape: Coil/sheet
Thickness: 1.14-6.0MM Model Number: T1,T2,T2,T4,T5,T6,T7
Thickness Tolerance: -+0.005mm MOQ: 1 Ton
High Light:

single reduced tin plate sheet

,

roofing tin plate sheet

,

single reduced steel tin plate

Roofing Metal Shed Single Reduced Tin Plate Sheet





Product Description.



Tinplate has the strength and formability of steel combined with the noncorrosive and nontoxic properties of tin and has the additional property of easy solderability. While it is largely used for containers for food and beverages, paints, oils, tobacco, and numerous other products, its use has broadened to include toys, baking equipment, and parts for radio and other electronic equipment.



Roofing Metal Shed Single Reduced Tin Plate Sheet 0

Specifications
Product Name
Tinplate(SPTE/ETP)
Standard
GB, JIS, DIN ,ASTM
Material
MR SPCC
Grade
Prime
Annealing
BA/CA
Thickness
0.14-6.0mm
Width
600-1500mm
Temper
T1, T2, T3, T4, T5, DR7, DR8, DR9, TH550, TH580, TH620, TH660
Coating(g/m2)
1.1/1, 2.0/2.0, 2.8/2.8, 2.8/5.6, 5.6/5.6, 8.4/8.4, 11.2/11.2, etc
Surface Finish
Stone, Bright, Silver
Packaging
Standard export packing.
or according to customer's requirements.
Payment
T/T or L/C or D/P



Product Introduction

Tinplate(SPTE) is a common name for electroplated tin steel sheets, which refers to cold-rolled low-carbon steel sheets or strips coated with commercial pure tin on both sides. Tin mainly acts to prevent corrosion and rust. It combines the strength and formability of steel with the corrosion resistance, solderability and aesthetic appearance of tin in a material with corrosion resistance, non-toxicity, high strength and good ductility.Tin-plate packaging has a wide range of coverage in the packaging industry because of its good sealing, preservation, light-proof, ruggedness and unique metal decoration charm. Because of its strong antioxidant, diverse styles and exquisite printing, tinplate packaging container is popular with customers, and widely used in food packaging, pharmaceutical packaging, commodity packaging, instrument packaging, industrial packaging and so on.

Roofing Metal Shed Single Reduced Tin Plate Sheet 1Roofing Metal Shed Single Reduced Tin Plate Sheet 2Roofing Metal Shed Single Reduced Tin Plate Sheet 3Roofing Metal Shed Single Reduced Tin Plate Sheet 4Roofing Metal Shed Single Reduced Tin Plate Sheet 5

Mechanical Properties
emper Grade
Hardness(HR30Tm)
Yield Strength(MPa)
T-1
49±3
330
T-2
53±3
350
T-3
57±3
370
T-4
61±3
415
T-5
65±3
450
T-6
70±3
530
DR-7M
71±5
520
DR-8
73±5
550
DR-8M
73±5
580
DR-9
76±5
620
DR-9M
77±5
660
DR-10
80±5
690



Coating Weight



Former Coating Designation
Nominal Coating Weight
(g/m2)
Minimum average Coating Weight (g/m2)
10#
1.1/1.1
0.9/0.9
20#
2.2/2.2
1.8/1.8
25#
2.8/2.8
2.5/2.5
50#
5.6/5.6
5.2/5.2
75#
8.4/8.4
7.8/7.8
100#
11.2/11.2
10.1/10.1
25#/10#
2.8/1.1
2.5/0.9
50#/10#
5.6/1.1
5.2/0.9
75#/25#
5.6/2.8
5.2/2.5
75#/50#
8.4/2.8
7.8/2.5
75#/50#
8.4/5.6
7.8/5.2
100#/25#
11.2/2.8
10.1/2.5
100#/50#
11.2/5.6
10.1/5.2
100#/75#
11.2/8.4
10.1/7.8
125#/50#
15.1/5.6
13.9/5.2


Applications

Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.Roofing Metal Shed Single Reduced Tin Plate Sheet 6
Quality Inspection
Roofing Metal Shed Single Reduced Tin Plate Sheet 7Roofing Metal Shed Single Reduced Tin Plate Sheet 8Roofing Metal Shed Single Reduced Tin Plate Sheet 9Roofing Metal Shed Single Reduced Tin Plate Sheet 10Roofing Metal Shed Single Reduced Tin Plate Sheet 11Roofing Metal Shed Single Reduced Tin Plate Sheet 12Roofing Metal Shed Single Reduced Tin Plate Sheet 13Roofing Metal Shed Single Reduced Tin Plate Sheet 14Roofing Metal Shed Single Reduced Tin Plate Sheet 15
FAQ:

Q1. What are your company's main products ?

A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

Q2. How do you control quality ?

A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.

Q3. What are the advantages of your company ?

A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q4. How many coutries you already exported ?

A4: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.

Q5. Can you provide sample ?

A5: We can provide the samll samples in stock for free, as long as you contact us.

Customized samples will take about 5-7days.
