Colored Double Reduced Steel Tin Plate / Sheet

Colored Double Reduced Steel Tin Plate / Sheet
Colored Double Reduced Steel Tin Plate / Sheet
Colored Double Reduced Steel Tin Plate / Sheet Colored Double Reduced Steel Tin Plate / Sheet Colored Double Reduced Steel Tin Plate / Sheet Colored Double Reduced Steel Tin Plate / Sheet

Large Image :  Colored Double Reduced Steel Tin Plate / Sheet

Product Details:
Place of Origin: CHINA
Brand Name: SYL
Certification: CE ISO
Model Number: tinplate
Payment & Shipping Terms:
Minimum Order Quantity: 1 ton
Price: ＄400-680/Metric Ton
Packaging Details: Standard seaworthy export packing or as customer demands
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union
Supply Ability: 5000 Ton/Tons per Month
Contact Now

Colored Double Reduced Steel Tin Plate / Sheet

Description
Tin Coating: 1.1-5.6 Model Number:: T1,T2,T2,T4,T5,T6,T7
Width:: 300-1500MM,etc Standard: JIS ASTM ASME GB DIN EN
Hardness:: T1-T5 Tolerance:: ±1%
Shape:: Coil/sheet Thickness:: 1.14-6.0MM
Packing: According To Customer Needs Certificate:: ISO9001,ce
Thickness Tolerance: -+0.005mm MOQ:: 1 Ton
High Light:

double reduced steel tin plate

,

colored steel tin plate

,

double reduced tin plate sheet

Colored Tin Plate/Tinplate Metal Sheeting Corrugated Sheet House Roofing Sheet Price Sheets Roof Tin Lowes Panels



Product Description.


Tinplate(ETP) consists of sheets of steel coated electrolytically with a thin layer of tin. It in itself has strength of steel and the non-corrosive,lustrous,weldable properties of tin.
ETP may be Single Reduced (SR) or Double Reduced (DR) type and is available both in sheet and /or coil form.
It certainly is the preferred choice for packaging materials.
Depending on user requirement tinplate of various types with:
different formabilities (“tempers”)
steel thicknesses (from 0.13 mm to 0.65 mm)
finishes like bright, stone, silver matte, silver bright, matte is available




Colored Double Reduced Steel Tin Plate / Sheet 0


Specifications
Product Name
Tinplate(SPTE/ETP)
Standard
GB, JIS, DIN ,ASTM
Material
MR SPCC
Grade
Prime
Annealing
BA/CA
Thickness
0.14-6.0mm
Width
600-1500mm
Temper
T1, T2, T3, T4, T5, DR7, DR8, DR9, TH550, TH580, TH620, TH660
Coating(g/m2)
1.1/1, 2.0/2.0, 2.8/2.8, 2.8/5.6, 5.6/5.6, 8.4/8.4, 11.2/11.2, etc
Surface Finish
Stone, Bright, Silver
Packaging
Standard export packing.
or according to customer's requirements.
Payment
T/T or L/C or D/P



Product Introduction

Tinplate(SPTE) is a common name for electroplated tin steel sheets, which refers to cold-rolled low-carbon steel sheets or strips coated with commercial pure tin on both sides. Tin mainly acts to prevent corrosion and rust. It combines the strength and formability of steel with the corrosion resistance, solderability and aesthetic appearance of tin in a material with corrosion resistance, non-toxicity, high strength and good ductility.Tin-plate packaging has a wide range of coverage in the packaging industry because of its good sealing, preservation, light-proof, ruggedness and unique metal decoration charm. Because of its strong antioxidant, diverse styles and exquisite printing, tinplate packaging container is popular with customers, and widely used in food packaging, pharmaceutical packaging, commodity packaging, instrument packaging, industrial packaging and so on.

Colored Double Reduced Steel Tin Plate / Sheet 1Colored Double Reduced Steel Tin Plate / Sheet 2Colored Double Reduced Steel Tin Plate / Sheet 3Colored Double Reduced Steel Tin Plate / Sheet 4Colored Double Reduced Steel Tin Plate / Sheet 5

Mechanical Properties
emper Grade
Hardness(HR30Tm)
Yield Strength(MPa)
T-1
49±3
330
T-2
53±3
350
T-3
57±3
370
T-4
61±3
415
T-5
65±3
450
T-6
70±3
530
DR-7M
71±5
520
DR-8
73±5
550
DR-8M
73±5
580
DR-9
76±5
620
DR-9M
77±5
660
DR-10
80±5
690



Coating Weight



Former Coating Designation
Nominal Coating Weight
(g/m2)
Minimum average Coating Weight (g/m2)
10#
1.1/1.1
0.9/0.9
20#
2.2/2.2
1.8/1.8
25#
2.8/2.8
2.5/2.5
50#
5.6/5.6
5.2/5.2
75#
8.4/8.4
7.8/7.8
100#
11.2/11.2
10.1/10.1
25#/10#
2.8/1.1
2.5/0.9
50#/10#
5.6/1.1
5.2/0.9
75#/25#
5.6/2.8
5.2/2.5
75#/50#
8.4/2.8
7.8/2.5
75#/50#
8.4/5.6
7.8/5.2
100#/25#
11.2/2.8
10.1/2.5
100#/50#
11.2/5.6
10.1/5.2
100#/75#
11.2/8.4
10.1/7.8
125#/50#
15.1/5.6
13.9/5.2


Applications

Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.
Colored Double Reduced Steel Tin Plate / Sheet 6Colored Double Reduced Steel Tin Plate / Sheet 7Colored Double Reduced Steel Tin Plate / Sheet 8

Colored Double Reduced Steel Tin Plate / Sheet 9Colored Double Reduced Steel Tin Plate / Sheet 10Colored Double Reduced Steel Tin Plate / Sheet 11Colored Double Reduced Steel Tin Plate / Sheet 12Colored Double Reduced Steel Tin Plate / Sheet 13Colored Double Reduced Steel Tin Plate / Sheet 14Colored Double Reduced Steel Tin Plate / Sheet 15Colored Double Reduced Steel Tin Plate / Sheet 16



FAQ:

Q1. What are your company's main products ?

A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

Q2. How do you control quality ?

A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.

Q3. What are the advantages of your company ?

A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q4. How many coutries you already exported ?

A4: Exported to more than 50 countries mainly from America, , UK, Kuwait, Egypt, Turkey, Jordan,India, etc.

Q5. Can you provide sample ?

A5: We can provide the samll samples in stock for free, as long as you contact us.

Customized samples will take about 5-7days.
