0.18mm Electrolytic Tinplate Coil For Aerosol Can Manufacturing 885mm Width
Product Details
| Tempe: | T1-T5 | Shape: | Flat/ Sheet, Coils |
|---|---|---|---|
| Productname: | ETP Steel Tin Plate | Applications: | Food Packaging, Beverage Cans, Aerosol Cans |
| Surfacefinish: | Bright Or Matte | Technique: | BA Or CA |
| Packing: | According To Customer Needs | Material: | Cold Rolled Steel |
| Highlight |
0.18mm Electrolytic Tinplate Coil,885mm Electrolytic Tinplate Coil,Aerosol Can tin plate coil |
||
Product Description
Tinplate (ETP) consists of sheets of steel coated electrolytically with a thin layer of tin. It combines the strength of steel with the non-corrosive, lustrous, and weldable properties of tin.
ETP may be Single Reduced (SR) or Double Reduced (DR) type and is available in both sheet and coil form. It is the preferred choice for packaging materials.
| Product Name | 0.18mm Electrolytic Tin Plate Coils for Aerosol Can Manufacturing - 885mm Width |
|---|---|
| Standard | JIS G3303, ASTM A623 |
| Material | MR SPCC |
| Grade | Prime |
| Annealing | BA/CA |
| Thickness | 0.16-3.0mm |
| Width | 600-1500mm |
| Temper | T1, T2, T3, T4, T5, DR7, DR8, DR9, TH550, TH580, TH620, TH660 |
| Coating (g/m²) | 1.1/1, 2.0/2.0, 2.8/2.8, 2.8/5.6, 5.6/5.6, 8.4/8.4, 11.2/11.2, etc |
| Surface Finish | Stone, Bright, Silver, Matte |
| Packaging | Standard export packing or according to customer's requirements |
| Payment | T/T or L/C or D/P |
| Temper Grade | Hardness (HR30Tm) | Yield Strength (MPa) |
|---|---|---|
| T-1 | 49±3 | 330 |
| T-2 | 53±3 | 350 |
| T-3 | 57±3 | 370 |
| T-4 | 61±3 | 415 |
| T-5 | 65±3 | 450 |
| T-6 | 70±3 | 530 |
| DR-7M | 71±5 | 520 |
| DR-8 | 73±5 | 550 |
| DR-8M | 73±5 | 580 |
| DR-9 | 76±5 | 620 |
| DR-9M | 77±5 | 660 |
| DR-10 | 80±5 | 690 |
| Former Coating Designation | Nominal Coating Weight (g/m²) | Minimum Average Coating Weight (g/m²) |
|---|---|---|
| 10# | 1.1/1.1 | 0.9/0.9 |
| 20# | 2.2/2.2 | 1.8/1.8 |
| 25# | 2.8/2.8 | 2.5/2.5 |
| 50# | 5.6/5.6 | 5.2/5.2 |
| 75# | 8.4/8.4 | 7.8/7.8 |
| 100# | 11.2/11.2 | 10.1/10.1 |
| 25#/10# | 2.8/1.1 | 2.5/0.9 |
| 50#/10# | 5.6/1.1 | 5.2/0.9 |
| 75#/25# | 5.6/2.8 | 5.2/2.5 |
| 75#/50# | 8.4/2.8 | 7.8/2.5 |
| 75#/50# | 8.4/5.6 | 7.8/5.2 |
| 100#/25# | 11.2/2.8 | 10.1/2.5 |
| 100#/50# | 11.2/5.6 | 10.1/5.2 |
| 100#/75# | 11.2/8.4 | 10.1/7.8 |
| 125#/50# | 15.1/5.6 | 13.9/5.2 |
Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP Tinplate.
Tinplate is cold-rolled low-carbon steel sheet coated with a thin layer of tin on both surfaces. It combines the strength of steel with the corrosion resistance and solderability of tin.
Main applications:
- Food packaging: Canned food, beverage cans, milk powder cans, cooking oil cans
- Industrial packaging: Aerosol cans, paint cans, chemical containers
- Consumer goods: Gift boxes, tea cans, battery shells, metal signs
Tinplate is corrosion-resistant, but under extreme conditions (prolonged exposure to moisture, acids, or salt spray), rust may occur.
Our anti-rust measures:
- DOS oil coating: Food-grade oil applied to the surface
- Passivation treatment: Chromate passivation for enhanced corrosion resistance
- Professional packaging: Moisture-proof paper and plastic film wrapping suitable for long ocean shipments
For applications requiring superior corrosion resistance, we also offer tin-free steel (TFS).
Yes to both.
Custom cutting: We slit and shear coils to your exact sheet dimensions. Tolerances within ±0.1mm.
Custom printing: While we specialize in tinplate substrate, we work with trusted partner printing facilities. If you require pre-printed sheets (coating, printing, varnishing), we can arrange one-stop purchasing.
We use standard export-ready packaging:
- Inner: Moisture-proof kraft paper + anti-rust film
- Outer: Galvanized steel strapping + wooden pallets or seaworthy wooden crates
Suitable for container loading and long-distance ocean freight.
Simply contact us with your specifications:
- Thickness: ______ mm
- Width: ______ mm
- Tin coating: ______ g/m²
- Temper: ______
- Quantity: ______ tons
- Destination port: ______
We will provide a detailed quotation within 2 hours.
