0.18mm Electrolytic Tinplate Coil For Aerosol Can Manufacturing 885mm Width

5 Tons
MOQ
negotiated
Price
0.18mm Electrolytic Tinplate Coil For Aerosol Can Manufacturing 885mm Width
Features Gallery Product Description Chat Now
Features
Specifications
Tempe: T1-T5
Shape: Flat/ Sheet, Coils
Productname: ETP Steel Tin Plate
Applications: Food Packaging, Beverage Cans, Aerosol Cans
Surfacefinish: Bright Or Matte
Technique: BA Or CA
Packing: According To Customer Needs
Material: Cold Rolled Steel
Highlight:

0.18mm Electrolytic Tinplate Coil

,

885mm Electrolytic Tinplate Coil

,

Aerosol Can tin plate coil
Basic Infomation
Place of Origin: China
Brand Name: Wuxi talat
Certification: Manufacture certificate
Model Number: MR SPCC
Payment & Shipping Terms
Packaging Details: standard seaworthy package
Delivery Time: 15-20days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 10000Tons
Product Description

0.18mm Electrolytic Tin Plate Coils for Aerosol Can Manufacturing- 885mm Width

Product Description



Tinplate(ETP) consists of sheets of steel coated electrolytically with a thin layer of tin. It in itself has strength of steel and the non-corrosive,lustrous,weldable properties of tin.
ETP may be Single Reduced (SR) or Double Reduced (DR) type and is available both in sheet and /or coil form.
It certainly is the preferred choice for packaging materials.
Depending on user requirement tinplate of various types with:
different formabilities (“tempers”)
steel thicknesses (from 0.13 mm to 0.65 mm)
finishes like bright, stone, silver matte, silver bright, matte is available

Specifications
Product Name
0.18mm Electrolytic Tin Plate Coils for Aerosol Can Manufacturing- 885mm Width
Standard
GB, JIS, DIN ,ASTM
Material
MR SPCC
Grade
Prime
Annealing
BA/CA
Thickness
0.16-3.0mm
Width
600-1500mm
Temper
T1, T2, T3, T4, T5, DR7, DR8, DR9, TH550, TH580, TH620, TH660
Coating(g/m2)
1.1/1, 2.0/2.0, 2.8/2.8, 2.8/5.6, 5.6/5.6, 8.4/8.4, 11.2/11.2, etc
Surface Finish
Stone, Bright, Silver
Packaging
Standard export packing.
or according to customer's requirements.
Payment
T/T or L/C or D/P



Tinplate(SPTE) is a common name for electroplated tin steel sheets, which refers to cold-rolled low-carbon steel sheets or strips coated with commercial pure tin on both sides. Tin mainly acts to prevent corrosion and rust. It combines the strength and formability of steel with the corrosion resistance, solderability and aesthetic appearance of tin in a material with corrosion resistance, non-toxicity, high strength and good ductility.Tin-plate packaging has a wide range of coverage in the packaging industry because of its good sealing, preservation, light-proof, ruggedness and unique metal decoration charm. Because of its strong antioxidant, diverse styles and exquisite printing, tinplate packaging container is popular with customers, and widely used in food packaging, pharmaceutical packaging, commodity packaging, instrument packaging, industrial packaging and so on.

0.18mm Electrolytic Tinplate Coil For Aerosol Can Manufacturing 885mm Width 00.18mm Electrolytic Tinplate Coil For Aerosol Can Manufacturing 885mm Width 10.18mm Electrolytic Tinplate Coil For Aerosol Can Manufacturing 885mm Width 2

Mechanical Properties
emper Grade
Hardness(HR30Tm)
Yield Strength(MPa)
T-1
49±3
330
T-2
53±3
350
T-3
57±3
370
T-4
61±3
415
T-5
65±3
450
T-6
70±3
530
DR-7M
71±5
520
DR-8
73±5
550
DR-8M
73±5
580
DR-9
76±5
620
DR-9M
77±5
660
DR-10
80±5
690



Coating Weight



Former Coating Designation
Nominal Coating Weight
(g/m2)
Minimum average Coating Weight (g/m2)
10#
1.1/1.1
0.9/0.9
20#
2.2/2.2
1.8/1.8
25#
2.8/2.8
2.5/2.5
50#
5.6/5.6
5.2/5.2
75#
8.4/8.4
7.8/7.8
100#
11.2/11.2
10.1/10.1
25#/10#
2.8/1.1
2.5/0.9
50#/10#
5.6/1.1
5.2/0.9
75#/25#
5.6/2.8
5.2/2.5
75#/50#
8.4/2.8
7.8/2.5
75#/50#
8.4/5.6
7.8/5.2
100#/25#
11.2/2.8
10.1/2.5
100#/50#
11.2/5.6
10.1/5.2
100#/75#
11.2/8.4
10.1/7.8
125#/50#
15.1/5.6
13.9/5.2


Applications

Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP Tinplate.



FAQ:

Q1. What are your company's main products ?

A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

Q2. How do you control quality ?

A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.

Q3. What are the advantages of your company ?

A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q4. How many coutries you already exported ?

A4: Exported to more than 50 countries mainly from America, , UK, Kuwait, Egypt, Turkey, Jordan,India, etc.

Q5. Can you provide sample ?

A5: We can provide the samll samples in stock for free, as long as you contact us.

Customized samples will take about 5-7days.
