Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm

Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm
Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm
Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm

Large Image :  Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm

Product Details:
Place of Origin: CHINA
Brand Name: SYL
Certification: CE ISO
Model Number: tinplate
Payment & Shipping Terms:
Minimum Order Quantity: 5 tons
Price: $800-1000/Metric Ton
Packaging Details: Standard seaworthy export packing or as customer demands
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, L/C, D/A, D/P
Supply Ability: 2000 Ton/Tons per Month

Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm

Description
Product Name: Prime Electrolytic Tinplate Feature: Good Weldability
Width: 585mm-995mm Colour: Tin Colour
Type: Coil Surface: Color Coated Or Tin Painted
Thickness: 0.12mm--0.41mm Material: SPCC; MR; D; L
High Light:

Electrolytic Tinplate Good Weldability

,

DIN EN 10203 Electrolytic Tin plate

,

600mm Electrolytic Tin plate

Tin Colour Prime Electrolytic Tinplate Good Weldability



Product Introduction



Tinplate, a tin coated steel, is the most sustainable and versatile packaging substrate which finds usage across a wide-end uses viz; food (edible oil, processed fruits & vegetables), non-food (paints & chemicals, aerosol sprays, battery) and beverages.



Features



* Beautiful surface luster

Has a characteristic, beautiful metallic luster.

* Good weldability

Easy to weld and solder.

* Excellent corrosion resistance

Has excellent corrosion resistance and is widely used for food cans.



Specifications



Tinplate
PRODUCT Prime tinplate
STANDARD BS EN 10202, DIN EN 10203, GB/T2520, JIS G3303
Grade Prime
Annealing BA CA
SIZE thickness: 0.15-0.5mm
width: 600-1050mm
TEMPER T2-T4,DR7 DR8 DR9
COATING 1.1-8.4g/m2
FINISH Stone, Bright, Silver
PACKING Standard export packing, or according to customer's requirements.
MOQ 1 ton
DELIVERY 15-30 days after receipt of original L/C or pre-payment
PAYMENT T/T or L/C



JIANGSU SENYILU METAL MATERIAL CO., LTD supplies different specifications of Double reduced (DR) tinplate and Single reduced (SR) tinplate.



It can be used in many parts,such as food can, oil cans and caps. At present, tinplates have been exported to many countries around the world, such as Egypt, Russia, Myanmar, Thailand and other countries. It is widely used in food packaging and chemical product packagings. We can provide high-quality tinplates that meet international standards.



Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm 0



Coating Structure

Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm 1

Production Process

Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm 2



Mechanical Properties

Temper Grade

Hardness(HR30Tm)

Yield Strength(MPa)

T-1

49±3

330

T-2

53±3

350

T-3

57±3

370

T-4

61±3

415

T-5

65±3

450

T-6

70±3

530

DR-7M

71±5

520

DR-8

73±5

550

DR-8M

73±5

580

DR-9

76±5

620

DR-9M

77±5

660

DR-10

80±5

690



Coating Weight

Former Coating Designation

Nominal Coating Weight
(g/m2)

Minimum average Coating Weight (g/m2)

10#

1.1/1.1

0.9/0.9

20#

2.2/2.2

1.8/1.8

25#

2.8/2.8

2.5/2.5

50#

5.6/5.6

5.2/5.2

75#

8.4/8.4

7.8/7.8

100#

11.2/11.2

10.1/10.1

25#/10#

2.8/1.1

2.5/0.9

50#/10#

5.6/1.1

5.2/0.9

75#/25#

5.6/2.8

5.2/2.5

75#/50#

8.4/2.8

7.8/2.5

75#/50#

8.4/5.6

7.8/5.2

100#/25#

11.2/2.8

10.1/2.5

100#/50#

11.2/5.6

10.1/5.2

100#/75#

11.2/8.4

10.1/7.8

125#/50#

15.1/5.6

13.9/5.2



Applications ans Cases

Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.

Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm 3

Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm 4

Colour Prime Electrolytic Tinplate Good Weldability DIN EN 10203 600mm 5



FAQ:



Q1. What are your company's main products ?

A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

Q2. How do you control quality ?

A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.

Q3. What are the advantages of your company ?

A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other steel companies.

Q4. How many coutries you already exported ?

A4: Exported to more than 50 countries mainly to Egypt, Russia, Myanmar, Thailand etc.

Q5. Can you provide sample ?

A5: We can provide the samll samples in stock for free, as long as you contact us.

Customized samples will take about 5-7days.
