Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers

Certification
China Jiangsu Senyilu Metal Material Co., Ltd. certification
China Jiangsu Senyilu Metal Material Co., Ltd. certification
Customer Reviews
การบริการของลีโอนั้น ยอดเยี่ยมมาก และทำงานกับเขาเป็นเวลานานในการจัดส่ง ที่รวดเร็ว และให้เครดิต

—— ทรงพระเจริญ

It is the third time that we have cooperated with Ms Melinda, and I am really touched by their honesty and sincerity. We have gained a lot every time we do it.

—— Mark

I'm Online Chat Now

Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers

Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers
Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers
Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers

Large Image :  Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers

Product Details:
Place of Origin: CHINA
Brand Name: SYL
Certification: CE ISO
Model Number: tinplate
Payment & Shipping Terms:
Minimum Order Quantity: 5 tons
Price: $800-1000/Metric Ton
Packaging Details: Standard seaworthy export packing or as customer demands
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, L/C, D/A, D/P
Supply Ability: 2000 Ton/Tons per Month

Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers

Description
Product Name: MR Steel Tin Plate Cold Rolled Bright Finish 5.6/5.6 5.6/2.8 Used For Food Containers Width: 585mm-985mm
Colour: Gold Colour Or Tin Colour Type: Flat Plate
Surface Treatment: Tin Plated Application: Container Plate,easy Open Ends Tab
Thickness: 0.14mm--0.45mm Standard: EN10202 And JIS3303
High Light:

Bright Finish MR Steel Tinplate

,

5.6/5.6 MR Steel Tin plate

,

MR Steel Tin plate 5.6/2.8

MR Steel Tin Plate Cold Rolled Bright Finish 5.6/5.6 5.6/2.8 used for food containers



Product Introduction



Why is tin such a popular choice for electroplating? Perhaps the biggest reason is that tin plating — or “tinning” — is an extremely cost-effective process. Because tin is so readily available, it is much less expensive than pricier metals such as gold, platinum or palladium. Tin also offers excellent solderability,  as well as superior protection against corrosion.





Tin plating can produce a whitish-gray color that is preferable when a dull or matte appearance is desired. It can also produce a shiny, metallic look when a bit more luster is preferred. Tin offers a decent level of conductivity, making tin plating useful in the manufacturing of various electronic components. Tin is also FDA approved for use in the food service industry.





Specifications



Product Name

 MR Steel Tin Plate Cold Rolled Bright Finish 5.6/5.6 5.6/2.8 used for food containers

Standard

JIS

Material

MR; SPCC

Grade

Prime

Annealing

BA/ CA

Thickness

0.14-0.45mm

Width

As customer required and ordered

Temper

T1, T2, T3, T4, T5, DR-7m, DR-8, DR-8m

Coating(g/m2)

1.1/1.1  2.8/2.8

Surface Finish

Stone finish; Bright finish; Silver Finish; Matte Finish

Packaging

Standard export packing or according to customer's requirements.

Payment

T/T or L/C



JIANGSU SENYILU METAL MATERIAL CO., LTD supplies different specifications of Double reduced (DR) tinplate and Single reduced (SR) tinplate.



It can be used in many parts,such as food can, oil cans and caps. At present, tinplates have been exported to many countries around the world, such as Egypt, Russia, Myanmar, Thailand and other countries. It is widely used in food packaging and chemical product packagings. We can provide high-quality tinplates that meet international standards.



Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers 0



Coating Structure

Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers 1

Production Process

Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers 2



Mechanical Properties

Temper Grade

Hardness(HR30Tm)

Yield Strength(MPa)

T-1

49±3

330

T-2

53±3

350

T-3

57±3

370

T-4

61±3

415

T-5

65±3

450

T-6

70±3

530

DR-7M

71±5

520

DR-8

73±5

550

DR-8M

73±5

580

DR-9

76±5

620

DR-9M

77±5

660

DR-10

80±5

690



Coating Weight

Former Coating Designation

Nominal Coating Weight
(g/m2)

Minimum average Coating Weight (g/m2)

10#

1.1/1.1

0.9/0.9

20#

2.2/2.2

1.8/1.8

25#

2.8/2.8

2.5/2.5

50#

5.6/5.6

5.2/5.2

75#

8.4/8.4

7.8/7.8

100#

11.2/11.2

10.1/10.1

25#/10#

2.8/1.1

2.5/0.9

50#/10#

5.6/1.1

5.2/0.9

75#/25#

5.6/2.8

5.2/2.5

75#/50#

8.4/2.8

7.8/2.5

75#/50#

8.4/5.6

7.8/5.2

100#/25#

11.2/2.8

10.1/2.5

100#/50#

11.2/5.6

10.1/5.2

100#/75#

11.2/8.4

10.1/7.8

125#/50#

15.1/5.6

13.9/5.2



Applications ans Cases

Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.

Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers 3

Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers 4

Cold Rolled MR Steel Tin Plate Bright Finish 5.6 / 5.6 5.6 / 2.8 Used For Food Containers 5
