Product Details:
|
Product Name: | Food Grade ETP Tinplate Electrolytic Tinplate For Tin Cans Containers | Standard: | JIS3303 Or EN10202 |
---|---|---|---|
Width: | 600mm-1000mm | Type: | Coils And Sheets |
Length: | Can Be Ordered | Thickness: | 0.16mm--0.25mm |
Technique: | BA Or CA | Application: | Container Plate,easy Open Ends Tab,Automobile |
Highlight: | Food Grade ETP Electrolytic Tinplate,JIS 3303 ETP Electrolytic Tinplate,1000mm ETP Electrolytic Tin plate |
Food Grade ETP Tinplate Electrolytic Tinplate For Tin Cans Containers
Product Introduction
Electrolytic Tin Plate is characterized by its beautiful metallic luster. Products with various kinds of surface roughness are produced by selecting the surface finish of the substrate steel sheet. Electrolytic Tin Plates have excellent paintability and printability. Printing is beautifully finished using various lacquers and inks.
Our cuatomers buy ETP tinplate for food containers and can packagings. This kind of tinplate sheet is very popular in cannery containers, because it isn't harmful to people's body.
Specifications
Product Name |
Food Grade ETP Tinplate Electrolytic Tinplate For Tin Cans Containers |
Standard |
JIS |
Material |
MR; SPCC |
Grade |
Prime |
Annealing |
BA/ CA |
Thickness |
0.16-1.0mm |
Width |
As customer required and ordered |
Temper |
T1, T2, T3, T4, T5, DR-7m, DR-8, DR-8m |
Coating(g/m2) |
1.1/1.1 2.0/2.0 2.8/2.8 |
Surface Finish |
Stone finish; Bright finish |
Packaging |
Standard export packing or according to customer's requirements. |
Payment |
T/T or L/C |
JIANGSU SENYILU METAL MATERIAL CO., LTD supplies different specifications of Double reduced (DR) tinplate and Single reduced (SR) tinplate.
It can be used in many parts,such as food can, oil cans and caps. At present, tinplates have been exported to many countries around the world, such as Egypt, , Myanmar, Thailand and other countries. It is widely used in food packaging and chemical product packagings. We can provide high-quality tinplates that meet international standards.
Coating Structure
Production Process
Mechanical Properties
Temper Grade |
Hardness(HR30Tm) |
Yield Strength(MPa) |
T-1 |
49±3 |
330 |
T-2 |
53±3 |
350 |
T-3 |
57±3 |
370 |
T-4 |
61±3 |
415 |
T-5 |
65±3 |
450 |
T-6 |
70±3 |
530 |
DR-7M |
71±5 |
520 |
DR-8 |
73±5 |
550 |
DR-8M |
73±5 |
580 |
DR-9 |
76±5 |
620 |
DR-9M |
77±5 |
660 |
DR-10 |
80±5 |
690 |
Coating Weight
Former Coating Designation |
Nominal Coating Weight |
Minimum average Coating Weight (g/m2) |
10# |
1.1/1.1 |
0.9/0.9 |
20# |
2.2/2.2 |
1.8/1.8 |
25# |
2.8/2.8 |
2.5/2.5 |
50# |
5.6/5.6 |
5.2/5.2 |
75# |
8.4/8.4 |
7.8/7.8 |
100# |
11.2/11.2 |
10.1/10.1 |
25#/10# |
2.8/1.1 |
2.5/0.9 |
50#/10# |
5.6/1.1 |
5.2/0.9 |
75#/25# |
5.6/2.8 |
5.2/2.5 |
75#/50# |
8.4/2.8 |
7.8/2.5 |
75#/50# |
8.4/5.6 |
7.8/5.2 |
100#/25# |
11.2/2.8 |
10.1/2.5 |
100#/50# |
11.2/5.6 |
10.1/5.2 |
100#/75# |
11.2/8.4 |
10.1/7.8 |
125#/50# |
15.1/5.6 |
13.9/5.2 |
Applications ans Cases
Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.
FAQ:
Q1. What are your company's main products ?
A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.
Q2. How do you control quality ?
A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.
Q3. What are the advantages of your company ?
A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q4. How many coutries you already exported ?
A4: Exported to more than 50 countries mainly to Egypt, , Myanmar, Thailand etc.
Q5. Can you provide sample ?
A5: We can provide the samll samples in stock for free, as long as you contact us.
Customized samples will take about 5-7days.
