Product Details:
|
| Product Name: | Tin Plate For Tinplate Printing Service For Laminated Can And Can Cap JIS G3303 | Standard: | JIS |
|---|---|---|---|
| Technique: | Cold Rolled | Thickness: | 0.16mm; 0.17mm; 0.18mm; 0.19mm; 0.20mm |
| Surface: | Stone Finished | Colour: | Tin Colour |
| Material: | MR; SPCC | Temper: | T1, T2, T3, T4, T5 |
| High Light: | MR Steel Tinplate For Laminated Can,JIS G3303 MR Steel Tinplate,0.18mm MR Steel Tin plate |
||
Tin Plate For Tinplate Printing Service For Laminated Can And Can Cap JIS G3303
Product Introduction
Tin layer works as a safe substance between the metal and the food. Tin helps utensils made of brass and copper increase its conductivity which also reduces the fuel cost. With regular intervals re-tinning, it also maintains the taste of the food.
Tin is a silver-white metal that is soft, ductile and malleable. Due to this flexibility, tin can be molded and stretched into a variety of shapes without cracking. Tin is also considered to be non-toxic, conductive and resistant to corrosion.
Specifications
|
Product Name |
Tin Plate For Tinplate Printing Service For Laminated Can And Can Cap JIS G3303 |
|
Standard |
JIS |
|
Material |
MR |
|
Grade |
Prime |
|
Annealing |
BA/ CA |
|
Thickness |
0.16-1.0mm |
|
Width |
As customer required and ordered |
|
Temper |
T1, T2, T3, T4, T5, DR-7m, DR-8, DR-8m |
|
Coating(g/m2) |
1.1/1.1 2.0/2.0 2.8/2.8 |
|
Surface Finish |
Stone finish |
|
Packaging |
Standard export packing or according to customer's requirements. |
|
Payment |
T/T or L/C |
JIANGSU SENYILU METAL MATERIAL CO., LTD supplies different specifications of Double reduced (DR) tinplate and Single reduced (SR) tinplate.
It can be used in many parts,such as food can, oil can and caps. At present, tinplates have been exported to many countries around the world, such as Egypt, Russia, Myanmar, Thailand and other countries. It is widely used in food packaging and chemical product packagings. We can provide high-quality tinplates that meet international standards.
Coating Structure
Production Process
Mechanical Properties
|
Temper Grade |
Hardness(HR30Tm) |
Yield Strength(MPa) |
|
T-1 |
49±3 |
330 |
|
T-2 |
53±3 |
350 |
|
T-3 |
57±3 |
370 |
|
T-4 |
61±3 |
415 |
|
T-5 |
65±3 |
450 |
|
T-6 |
70±3 |
530 |
|
DR-7M |
71±5 |
520 |
|
DR-8 |
73±5 |
550 |
|
DR-8M |
73±5 |
580 |
|
DR-9 |
76±5 |
620 |
|
DR-9M |
77±5 |
660 |
|
DR-10 |
80±5 |
690 |
Coating Weight
|
Former Coating Designation |
Nominal Coating Weight |
Minimum average Coating Weight (g/m2) |
|
10# |
1.1/1.1 |
0.9/0.9 |
|
20# |
2.2/2.2 |
1.8/1.8 |
|
25# |
2.8/2.8 |
2.5/2.5 |
|
50# |
5.6/5.6 |
5.2/5.2 |
|
75# |
8.4/8.4 |
7.8/7.8 |
|
100# |
11.2/11.2 |
10.1/10.1 |
|
25#/10# |
2.8/1.1 |
2.5/0.9 |
|
50#/10# |
5.6/1.1 |
5.2/0.9 |
|
75#/25# |
5.6/2.8 |
5.2/2.5 |
|
75#/50# |
8.4/2.8 |
7.8/2.5 |
|
75#/50# |
8.4/5.6 |
7.8/5.2 |
|
100#/25# |
11.2/2.8 |
10.1/2.5 |
|
100#/50# |
11.2/5.6 |
10.1/5.2 |
|
100#/75# |
11.2/8.4 |
10.1/7.8 |
|
125#/50# |
15.1/5.6 |
13.9/5.2 |
Applications
Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.
FAQ:
Q1. What are your company's main products ?
A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.
Q2. How do you control quality ?
A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.
Q3. What are the advantages of your company ?
A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q4. How many coutries you already exported ?
A4: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.
Q5. Can you provide sample ?
A5: We can provide the samll samples in stock for free, as long as you contact us.
Customized samples will take about 5-7days.
