SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can

SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can
SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can
SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can

Large Image :  SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can

Product Details:
Place of Origin: CHINA
Brand Name: SYL
Certification: CE ISO
Model Number: tinplate
Payment & Shipping Terms:
Minimum Order Quantity: 5 tons
Price: negotiated
Packaging Details: Standard seaworthy export packing or as customer demands
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, L/C, D/A, D/P
Supply Ability: 2000 Ton/Tons per Month

SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can

Description
Product Name: Good Quality SPCC Electrolytic Tinplate Sheet/coil For Oil Packaging/chemical Can Surface: Matte Finish
Base Plate: SPCC Thickness: 0.18 Mm And 0.24mm
Length: 550mm--990mm Temper: T3
Colour: Tin Colour Shape: Flat/ Sheet
Tin Coating: 2.8g/m2 Technique: Cold Rolled
High Light:

SPCC Electrolytic Tin plate Sheet

,

0.24mm Tin plate Sheet

,

2.8 g/m2 Tin plate Sheet

Good quality SPCC Electrolytic Tinplate Sheet/coil for Oil Packaging/chemical can



Product Introduction



Tinplate is a thin steel sheet coated by tin. It has an extremely beautiful metallic luster as well as excellent properties in corrosion resistance, solderability, and weldability.
Tinplate is used for making all types of containers such as food cans, beverage cans, 18-liter cans, and artistic cans. Its applications are not limited to containers; recently, tinplate has also been used for making electrical machinery parts and many other products.



Tinplate, thin steel sheet with a coating of tin applied either by dipping in molten metal or by electrolytic deposition; almost all tinplate is now produced by the latter process.



Tinplates made by this process is essentially a sandwich in which the central core is strip steel. This core is cleaned in a pickling solution and then fed through tanks containing electrolyte, where tin is deposited on both sides. As the strip passes between high-frequency electric induction coils, it is heated so that the tin coating melts and flows to form a lustrous coat. The end product has a tin coating of about 0.00003 inch (0.00076 millimetre) on each side.





Specifications

Product Name

Good quality SPCC Electrolytic Tinplate Sheet/coil for Oil Packaging/chemical can

Standard

JIS

Material

MR

Grade

Prime

Annealing

BA/ CA

Thickness

0.16-0.58mm

Width

As customer required

Temper

T1, T2, T3, T4, T5, DR8, DR9

Coating(g/m2)

2.8g/m2

Surface Finish

Stone, Bright, Sliver, Matte

Packaging

Standard export packing or according to customer's requirements.

Payment

T/T or L/C



JIANGSU SENYILU METAL MATERIAL CO., LTD supplies different specifications of Double reduced (DR) tinplate and Single reduced (SR) tinplate. It can be used in many parts,such as food can, oil can and caps. At present, tinplates have been exported to many countries around the world, such as Egypt, Iran, Myanmar, Thailand and other countries. It is widely used in food packaging and chemical product packagings. We can provide high-quality tinplate that meets international standards.

SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can 0



Coating Structure

SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can 1

Production Process

SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can 2



Mechanical Properties

Temper Grade

Hardness(HR30Tm)

Yield Strength(MPa)

T-1

49±3

330

T-2

53±3

350

T-3

57±3

370

T-4

61±3

415

T-5

65±3

450

T-6

70±3

530

DR-7M

71±5

520

DR-8

73±5

550

DR-8M

73±5

580

DR-9

76±5

620

DR-9M

77±5

660

DR-10

80±5

690



Coating Weight

Former Coating Designation

Nominal Coating Weight
(g/m2)

Minimum average Coating Weight (g/m2)

10#

1.1/1.1

0.9/0.9

20#

2.2/2.2

1.8/1.8

25#

2.8/2.8

2.5/2.5

50#

5.6/5.6

5.2/5.2

75#

8.4/8.4

7.8/7.8

100#

11.2/11.2

10.1/10.1

25#/10#

2.8/1.1

2.5/0.9

50#/10#

5.6/1.1

5.2/0.9

75#/25#

5.6/2.8

5.2/2.5

75#/50#

8.4/2.8

7.8/2.5

75#/50#

8.4/5.6

7.8/5.2

100#/25#

11.2/2.8

10.1/2.5

100#/50#

11.2/5.6

10.1/5.2

100#/75#

11.2/8.4

10.1/7.8

125#/50#

15.1/5.6

13.9/5.2



Applications

Tinplate is primarily used for packaging food stuffs and beverages,  it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP plate.

SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can 3

SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can 4









SPCC Electrolytic Tinplate Sheet 0.24mm For Chemical Can 5
