Product Details:
|
| Product Name: | Factory T2 T5 Hardness Electrolytic Tinplate Sheet Prices Tin Mill Black Plate | Material: | SPCC; MR |
|---|---|---|---|
| Thickness: | 0.16-0.6mm | Tin Coating: | 2.8g/m2; 1.1g/m2 |
| Temper: | T3-T5, DR8, DR9 | Length: | 550mm--990mm |
| Surface Treatment: | Tin Coated For Print | Colour: | Tin Colour |
| High Light: | Hardness Electrolytic Tinplate Sheet,0.5 mm T2 TinPlate,Tin Mill Black Plate |
||
Factory T2 T5 Hardness Electrolytic Tinplate Sheet Prices Tin Mill Black Plate
Product Introduction
Tinplate is made from the process of thinly coating sheets of wrought iron or steel with tin. It is most often used to prevent rust. The primary use of tinplate is the manufacture of tin cans in which foods and numerous other products are packed, as well as for household utensils of various kinds.
Tinplate has many advantages such as good sealing, preservation, light-proofing, firmness and unique metal decoration charm; strong oxidation resistance; high strength of tinplate packaging containers, good formability, and strong product compatibility. Tin has stable chemical properties and is not easily corroded.
Specifications
|
Product Name |
Factory T2 T5 Hardness Electrolytic Tinplate Sheet Prices Tin Mill Black Plate |
|
Standard |
JIS |
|
Material |
MR |
|
Grade |
Prime |
|
Annealing |
BA/ CA |
|
Thickness |
0.16-0.6mm |
|
Width |
As customer required |
|
Temper |
T1, T2, T3, T4, T5 |
|
Coating(g/m2) |
2.8/2.8 |
|
Surface Finish |
Stone, Bright, Sliver, Matte |
|
Packaging |
Standard export packing or according to customer's requirements. |
|
Payment |
T/T or L/C |
JIANGSU SENYILU METAL MATERIAL CO., LTD supplies different specifications of Double reduced (DR) tinplate and Single reduced (SR) tinplate. It can be used in many parts,such as food can, oil can and caps. At present, tinplates have been exported to many countries around the world, such as Egypt, Russia, Tunisia, Thailand and other countries. It is widely used in food packaging and chemical product packagings. We can provide high-quality tinplate that meets international standards.
Coating Structure
Production Process
Mechanical Properties
|
Temper Grade |
Hardness(HR30Tm) |
Yield Strength(MPa) |
|
T-1 |
49±3 |
330 |
|
T-2 |
53±3 |
350 |
|
T-3 |
57±3 |
370 |
|
T-4 |
61±3 |
415 |
|
T-5 |
65±3 |
450 |
|
T-6 |
70±3 |
530 |
|
DR-7M |
71±5 |
520 |
|
DR-8 |
73±5 |
550 |
|
DR-8M |
73±5 |
580 |
|
DR-9 |
76±5 |
620 |
|
DR-9M |
77±5 |
660 |
|
DR-10 |
80±5 |
690 |
Coating Weight
|
Former Coating Designation |
Nominal Coating Weight |
Minimum average Coating Weight (g/m2) |
|
10# |
1.1/1.1 |
0.9/0.9 |
|
20# |
2.2/2.2 |
1.8/1.8 |
|
25# |
2.8/2.8 |
2.5/2.5 |
|
50# |
5.6/5.6 |
5.2/5.2 |
|
75# |
8.4/8.4 |
7.8/7.8 |
|
100# |
11.2/11.2 |
10.1/10.1 |
|
25#/10# |
2.8/1.1 |
2.5/0.9 |
|
50#/10# |
5.6/1.1 |
5.2/0.9 |
|
75#/25# |
5.6/2.8 |
5.2/2.5 |
|
75#/50# |
8.4/2.8 |
7.8/2.5 |
|
75#/50# |
8.4/5.6 |
7.8/5.2 |
|
100#/25# |
11.2/2.8 |
10.1/2.5 |
|
100#/50# |
11.2/5.6 |
10.1/5.2 |
|
100#/75# |
11.2/8.4 |
10.1/7.8 |
|
125#/50# |
15.1/5.6 |
13.9/5.2 |
Applications
Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.
FAQ:
Q1. What are your company's main products ?
A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.
Q2. How do you control quality ?
A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.
Q3. What are the advantages of your company ?
A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q4. How many coutries you already exported ?
A4: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.
Q5. Can you provide sample ?
A5: We can provide the samll samples in stock for free, as long as you contact us.
Customized samples will take about 5-7days.
