Product Details:
|
Product Name: | Factory Price Flat Tin Sheet Print Sheet Coil For Food Application | Colour: | Tin Colour |
---|---|---|---|
Temper: | T2-T4, DR8, DR9 | Tin Coating: | 2.8/ 2.8; 1.1/1.1; 2.0/2.0 |
Material: | SPCC; MR | Shape: | Flat Steel Plate,coil |
Surface Treatment: | Tin Plated | Thickness: | 0.14-1.5mm |
Highlight: | Flat Steel Tinplate Sheet,1.5mm Flat Steel Tin Plate,Print Sheet Coil Tinplate |
Factory price flat tin sheet print sheet coil for food application
Product Introduction
Tinplate refers to a cold-rolled thin steel plate coated with a very thin layer of metallic tin on both sides, which combines the hardness and strength of steel with the ease of welding, corrosion resistance and bright appearance of tin.
Tin plate has the advantages of odorless, non-toxic, light weight, and easy to process and shape. Printing different patterns can also beautify the product, so it has been widely used in the food canning industry, electronic devices, chemical paint and other industries.
Specifications
Product Name |
Factory price flat tin sheet print sheet coil for food application |
Standard |
JIS |
Material |
SPCC/ MR |
Grade |
Prime |
Annealing |
BA/ CA |
Thickness |
0.14-1.4mm |
Width |
As required |
Temper |
T1, T2, T3, T4, T5 |
Coating(g/m2) |
1.1/1.1 2.0/2.0 2.8/2.8 5.6/5.6 11.2/5.6 11.2/11.2 |
Surface Finish |
Stone, Bright, Sliver, Matte |
Packaging |
Standard export packing or according to customer's requirements. |
Payment |
T/T or L/C |
JIANGSU SENYILU METAL MATERIAL CO., LTD supplies different specifications of Double reduced (DR) tinplate and Single reduced (SR) tinplate. It can be used in many parts,such as food can, oil can and caps. At present, tinplates have been exported to many countries around the world, such as Egypt, , Tunisia, Thailand and other countries. It is widely used in food packaging and chemical product packagings. We can provide high-quality tinplate that meets international standards.
Coating Structure
Production Process
Mechanical Properties
Temper Grade |
Hardness(HR30Tm) |
Yield Strength(MPa) |
T-1 |
49±3 |
330 |
T-2 |
53±3 |
350 |
T-3 |
57±3 |
370 |
T-4 |
61±3 |
415 |
T-5 |
65±3 |
450 |
T-6 |
70±3 |
530 |
DR-7M |
71±5 |
520 |
DR-8 |
73±5 |
550 |
DR-8M |
73±5 |
580 |
DR-9 |
76±5 |
620 |
DR-9M |
77±5 |
660 |
DR-10 |
80±5 |
690 |
Coating Weight
Former Coating Designation |
Nominal Coating Weight |
Minimum average Coating Weight (g/m2) |
10# |
1.1/1.1 |
0.9/0.9 |
20# |
2.2/2.2 |
1.8/1.8 |
25# |
2.8/2.8 |
2.5/2.5 |
50# |
5.6/5.6 |
5.2/5.2 |
75# |
8.4/8.4 |
7.8/7.8 |
100# |
11.2/11.2 |
10.1/10.1 |
25#/10# |
2.8/1.1 |
2.5/0.9 |
50#/10# |
5.6/1.1 |
5.2/0.9 |
75#/25# |
5.6/2.8 |
5.2/2.5 |
75#/50# |
8.4/2.8 |
7.8/2.5 |
75#/50# |
8.4/5.6 |
7.8/5.2 |
100#/25# |
11.2/2.8 |
10.1/2.5 |
100#/50# |
11.2/5.6 |
10.1/5.2 |
100#/75# |
11.2/8.4 |
10.1/7.8 |
125#/50# |
15.1/5.6 |
13.9/5.2 |
Applications
Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.
FAQ:
Q1. What are your company's main products ?
A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.
Q2. How do you control quality ?
A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.
Q3. What are the advantages of your company ?
A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q4. How many coutries you already exported ?
A4: Exported to more than 50 countries mainly from America, , UK, Kuwait, Egypt, Turkey, Jordan,India, etc.
Q5. Can you provide sample ?
A5: We can provide the samll samples in stock for free, as long as you contact us.
Customized samples will take about 5-7days.
