Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm

Certification
China Jiangsu Senyilu Metal Material Co., Ltd. certification
China Jiangsu Senyilu Metal Material Co., Ltd. certification
Customer Reviews
การบริการของลีโอนั้น ยอดเยี่ยมมาก และทำงานกับเขาเป็นเวลานานในการจัดส่ง ที่รวดเร็ว และให้เครดิต

—— ทรงพระเจริญ

It is the third time that we have cooperated with Ms Melinda, and I am really touched by their honesty and sincerity. We have gained a lot every time we do it.

—— Mark

I'm Online Chat Now

Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm

Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm
Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm
Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm

Large Image :  Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm

Product Details:
Place of Origin: CHINA
Brand Name: SYL
Certification: CE ISO
Model Number: tinplate
Payment & Shipping Terms:
Minimum Order Quantity: 5ton
Price: $800-1000/Metric Ton
Packaging Details: Standard seaworthy export packing or as customer demands
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, L/C, D/A, D/P
Supply Ability: 2000 Ton/Tons per Month

Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm

Description
Product Name: Metal Food Grade Paint Food Round Tin Can For Food Packaging Cans Type: Steel Plate
Application: Container Plate,easy Open Ends Tab,Automobile Technique: Cold Rolled
Standard: JIS3303 Material: MR; SPCC
Thickness: 0.16mm; 0.18mm; 0.19mm; 0.20mm;0.21mm Surface: Stone Finished, Bright Finish And Matte Finish
High Light:

Paint MR SPCC Steel Tin Plate

,

0.20 mm SPCC Steel Tin Plate

,

SPCC Steel Tin Plate 0.16mm

Metal Food Grade Paint Food Round Tin Can for Food Packaging Cans​



Product Introduction



Electrolytic tin plate coils and sheets for food metal packaging are thin steel plates coated with tin by electrolytic deposition. Tinplate made by this process is essentially a sandwich in which the central core is strip steel.



The core is cleaned in a pickling solution and tin is deposited on both sides through a tank containing an electrolyte. As the strip passes between high-frequency induction coils, it is heated so that the tin coating melts and flows, creating a shiny coating.



Our cuatomers buy ETP tinplate for food containers and can packagings. This kind of tinplate sheet is very popular in cannery conatiners, because it isn't harmful to people's body.



Specifications



Product Name

Metal Food Grade Paint Food Round Tin Can for Food Packaging Cans

Standard

JIS

Material

MR; SPCC

Grade

Prime

Annealing

BA/ CA

Thickness

0.16-1.0mm

Width

As customer required and ordered

Temper

T1, T2, T3, T4, T5, DR-7m, DR-8, DR-8m

Coating(g/m2)

1.1/1.1  2.0/2.0  2.8/2.8

Surface Finish

Stone finish; Bright finish

Packaging

Standard export packing or according to customer's requirements.

Payment

T/T or L/C



JIANGSU SENYILU METAL MATERIAL CO., LTD supplies different specifications of Double reduced (DR) tinplate and Single reduced (SR) tinplate.



It can be used in many parts,such as food can, oil cans and caps. At present, tinplates have been exported to many countries around the world, such as Egypt, Russia, Myanmar, Thailand and other countries. It is widely used in food packaging and chemical product packagings. We can provide high-quality tinplates that meet international standards.

Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm 0



Coating Structure

Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm 1

Production Process

Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm 2



Mechanical Properties

Temper Grade

Hardness(HR30Tm)

Yield Strength(MPa)

T-1

49±3

330

T-2

53±3

350

T-3

57±3

370

T-4

61±3

415

T-5

65±3

450

T-6

70±3

530

DR-7M

71±5

520

DR-8

73±5

550

DR-8M

73±5

580

DR-9

76±5

620

DR-9M

77±5

660

DR-10

80±5

690



Coating Weight

Former Coating Designation

Nominal Coating Weight
(g/m2)

Minimum average Coating Weight (g/m2)

10#

1.1/1.1

0.9/0.9

20#

2.2/2.2

1.8/1.8

25#

2.8/2.8

2.5/2.5

50#

5.6/5.6

5.2/5.2

75#

8.4/8.4

7.8/7.8

100#

11.2/11.2

10.1/10.1

25#/10#

2.8/1.1

2.5/0.9

50#/10#

5.6/1.1

5.2/0.9

75#/25#

5.6/2.8

5.2/2.5

75#/50#

8.4/2.8

7.8/2.5

75#/50#

8.4/5.6

7.8/5.2

100#/25#

11.2/2.8

10.1/2.5

100#/50#

11.2/5.6

10.1/5.2

100#/75#

11.2/8.4

10.1/7.8

125#/50#

15.1/5.6

13.9/5.2



Applications

Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.

Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm 3

Metal Food Grade Steel Tin Plate Paint MR SPCC For Food Packaging Can 0.20mm 4



FAQ:



Q1. What are your company's main products ?

A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

Q2. How do you control quality ?

A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.

Q3. What are the advantages of your company ?

A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q4. How many coutries you already exported ?

A4: Exported to more than 50 countries mainly to Egypt, Russia, Myanmar, Thailand etc.

Q5. Can you provide sample ?

A5: We can provide the samll samples in stock for free, as long as you contact us.

Customized samples will take about 5-7days.
