Electrolytic SPCC Steel Tinplate ETP For Food Containers

Electrolytic SPCC Steel Tinplate ETP For Food Containers
Electrolytic SPCC Steel Tinplate ETP For Food Containers
Electrolytic SPCC Steel Tinplate ETP For Food Containers Electrolytic SPCC Steel Tinplate ETP For Food Containers Electrolytic SPCC Steel Tinplate ETP For Food Containers Electrolytic SPCC Steel Tinplate ETP For Food Containers Electrolytic SPCC Steel Tinplate ETP For Food Containers

Large Image :  Electrolytic SPCC Steel Tinplate ETP For Food Containers

Product Details:
Place of Origin: CHINA
Brand Name: SYL
Certification: CE ISO
Model Number: tinplate
Payment & Shipping Terms:
Minimum Order Quantity: 1 ton
Price: $480-700/Metric Ton
Packaging Details: Standard seaworthy export packing or as customer demands
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, L/C, D/A, D/P
Supply Ability: 2000 Ton/Tons per Month

Electrolytic SPCC Steel Tinplate ETP For Food Containers

Description
Product Name: Electrolytic Tinplate Factory Price ETP For Food Containers Usage Thickness: 0.14-1.5mm
Tin Coating: 2.8/ 2.8; 1.1/1.1; 2.0/2.0 Colour: Tin Colour And Gold Colour
Temper: T1-T4, DR7, DR8, DR9 Length: As Customer Required
Surface Treatment: Tin Coated Material: SPCC; MR
High Light:

Electrolytic Tinplate ETP

,

Electrolytic SPCC Steel Tinplate

,

Tinplate For Food Containers

Electrolytic Tinplate factory Price ETP For food Containers Usage



Product Introduction

Tinplate refers to a cold-rolled thin steel plate coated with a very thin layer of metallic tin on both sides, which combines the hardness and strength of steel with the ease of welding, corrosion resistance and bright appearance of tin.

Tin plate has the advantages of odorless, non-toxic, light weight, and easy to process and shape. Printing different patterns can also beautify the product, so it has been widely used in the food canning industry, electronic devices, chemical paint and other industries.

Specifications



Product Name

 Electrolytic Tinplate factory Price ETP For food Containers Usage

Standard

JIS

Material

SPCC/ MR

Grade

Prime

Annealing

BA/ CA

Thickness

0.14-1.4mm

Width

As customer required

Temper

T1, T2, T3, T4, T5, DR-7m, DR-8, DR-8m

Coating(g/m2)

1.1/1.1  2.0/2.0  2.8/2.8  5.6/5.6

Surface Finish

Stone, Bright, Sliver, Matte

Packaging

Standard export packing or according to customer's requirements.

Payment

T/T or L/C



JIANGSU SENYILU METAL MATERIAL CO., LTD supplies different specifications of Double reduced (DR) tinplate and Single reduced (SR) tinplate. It can be used in many parts,such as food can, oil can and caps. At present, tinplates have been exported to many countries around the world, such as Egypt, Russia, Tunisia, Thailand and other countries. It is widely used in food packaging and chemical product packagings. We can provide high-quality tinplate that meets international standards.

Electrolytic SPCC Steel Tinplate ETP For Food Containers 0



Coating Structure

Electrolytic SPCC Steel Tinplate ETP For Food Containers 1

Production Process

Electrolytic SPCC Steel Tinplate ETP For Food Containers 2



Mechanical Properties

Temper Grade

Hardness(HR30Tm)

Yield Strength(MPa)

T-1

49±3

330

T-2

53±3

350

T-3

57±3

370

T-4

61±3

415

T-5

65±3

450

T-6

70±3

530

DR-7M

71±5

520

DR-8

73±5

550

DR-8M

73±5

580

DR-9

76±5

620

DR-9M

77±5

660

DR-10

80±5

690



Coating Weight

Former Coating Designation

Nominal Coating Weight
(g/m2)

Minimum average Coating Weight (g/m2)

10#

1.1/1.1

0.9/0.9

20#

2.2/2.2

1.8/1.8

25#

2.8/2.8

2.5/2.5

50#

5.6/5.6

5.2/5.2

75#

8.4/8.4

7.8/7.8

100#

11.2/11.2

10.1/10.1

25#/10#

2.8/1.1

2.5/0.9

50#/10#

5.6/1.1

5.2/0.9

75#/25#

5.6/2.8

5.2/2.5

75#/50#

8.4/2.8

7.8/2.5

75#/50#

8.4/5.6

7.8/5.2

100#/25#

11.2/2.8

10.1/2.5

100#/50#

11.2/5.6

10.1/5.2

100#/75#

11.2/8.4

10.1/7.8

125#/50#

15.1/5.6

13.9/5.2



Applications

Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.

Electrolytic SPCC Steel Tinplate ETP For Food Containers 3

Electrolytic SPCC Steel Tinplate ETP For Food Containers 4





FAQ:



Q1. What are your company's main products ?

A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

Q2. How do you control quality ?

A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.

Q3. What are the advantages of your company ?

A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q4. How many coutries you already exported ?

A4: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.

Q5. Can you provide sample ?

A5: We can provide the samll samples in stock for free, as long as you contact us.

Customized samples will take about 5-7days.
